Type: Brakes, Hydraulic
Manufacturer: CINCINNATI
Highlights: S/N N/A SPECS PER (RA/JG)(6/22/26) AARY PO#: EWR-7250 (6/22/26) PRICE:$44,500 FROM:JASON META PRODUCTS ├ THRU: IRONSIDE MACHINERY J/V: MAV 50% LOC: ONSITE
SPECIFICATIONS
TONNAGE ...................... 135 TONS
OVERALL LENGTH ............... 10'
DIST. BETWEEN HOUSINGS ....... 8'6"
BENDING CAP. (MILD STEEL) .... 3/16" X 10'3"
1/4" x 7'6"
1/2" x 4'8"
STROKE ....................... 8"
THROAT DEPTH ................. 7"
OPEN HEIGHT .................. 15"
CLOSED HEIGHT ................ 7"
RAM SPEED - HIGH ............. 136 IPM
MEDIUM ........... 65 IPM
LOW .............. 16 IPM
RETURN ........... 122 IPM
MOTOR ........................ 25 HP
Dimensions: 126" x 48" x 122" high
Weight: 16,000 lbs
CURRENTLY 480 VOLT / 3 PHASE
EQUIPPED WITH:
- GEN 6 UPDATED CINCINNATI CONTROL DONE IN 2025
- CNC CONTROL OVER THE RAM TRAVEL
- LOW, MEDIUM & HIGH SPEED MODES
- ADJUSTABLE TONNAGE
- PEDESTAL MOUNTED PALM BUTTONS
- FOOT PEDAL
- LOWER DIE RAIL
|
Stock #: 117322
SPECIFICATIONS
TONNAGE ...................... 135 TONSOVERALL LENGTH ............... 10'
DIST. BETWEEN HOUSINGS ....... 8'6"
BENDING CAP. (MILD STEEL) .... 3/16" X 10'3"
1/4" x 7'6"
1/2" x 4'8"
STROKE ....................... 8"
THROAT DEPTH ................. 7"
OPEN HEIGHT .................. 15"
CLOSED HEIGHT ................ 7"
RAM SPEED - HIGH ............. 136 IPM
MEDIUM ........... 65 IPM
LOW .............. 16 IPM
RETURN ........... 122 IPM
MOTOR ........................ 25 HP
Dimensions: 126" x 48" x 122" high
Weight: 16,000 lbs
CURRENTLY 480 VOLT / 3 PHASE
EQUIPPED WITH:
- GEN 6 UPDATED CINCINNATI CONTROL DONE IN 2025
- CNC CONTROL OVER THE RAM TRAVEL
- LOW, MEDIUM & HIGH SPEED MODES
- ADJUSTABLE TONNAGE
- PEDESTAL MOUNTED PALM BUTTONS
- FOOT PEDAL
- LOWER DIE RAIL
