New is 2022. Like new.
8" diameter Feed Rolls
Rated for up 1" diameter... 1 1/8" lower carbon
90" arm
50" line height
VF drive
110 fpm
Set up to run with an FX National with higher speed.
Includes:
One set of V grooved feed rolls 8 inch diameter
Dual coil support mandrels
Heavy duty I beam construction with a 50 inch wire line height
6,000 pound (2538KG) capacity (with an un-banded length of up to 90 inches
-5HP variable frequency drive with TEFC motor
-Speed range from 5 TO 130 FPM speed range
-Solid panel on guard for feed rolls and couple straightener
-Remote portable operators station with separate release buttons for feed head
-Guide roller on entrance to the feed head
-Storage for outboard roller pins with clamp screw
-HMI operators station
|
Stock #: 117145
New is 2022. Like new.
8" diameter Feed Rolls
Rated for up 1" diameter... 1 1/8" lower carbon
90" arm
50" line height
VF drive
110 fpm
Set up to run with an FX National with higher speed.
Includes:
One set of V grooved feed rolls 8 inch diameter
Dual coil support mandrels
Heavy duty I beam construction with a 50 inch wire line height
6,000 pound (2538KG) capacity (with an un-banded length of up to 90 inches
-5HP variable frequency drive with TEFC motor
-Speed range from 5 TO 130 FPM speed range
-Solid panel on guard for feed rolls and couple straightener
-Remote portable operators station with separate release buttons for feed head
-Guide roller on entrance to the feed head
-Storage for outboard roller pins with clamp screw
-HMI operators station
9 AMPS400/3/50 VOLTAGE
